Roma 69DC

High Resolution Tube DAC

Synthesis is set to release a new Digital to Analogue converter ROMA69DC.

The Roma 69DC has USB "B" type, DSD 5,6MHz and optical input. 32Bit of resolution give you a fantastic sound stage and beautiful sound reproduction.

Using a ECC88/6DJ8 on the output stage in as differential amplifier for a perfect matching with the Dac's output (Asahi Kasei AK4495S ), obtaining a very low output impedance and extremely large bandwidth. Paticular attention has been dedicated to the headphone output. Using a high-fidelity driver, we obtained a incredible natural sound performance, the sound stage is simply perfect!

To back this up the design has an over size shielded power transformer for reduce the interference. An array high grade metalized polipropilene capacitors controlling the audio signal circuits. The all important component of this unit are run by a multi stage fully regulated power supply.


Specifications

Digital Inputs

1 USB “B” type Windows/Mac/iOs/Android
2 Toslink Optical
2 S/PDIF Coaxial

D/A Converter

AK44995SEQ
32bit 768KHz

Max Resolution

24 bit 192KHz (OPT and COAX)
32 bit 384KHz (USB)
DSD fup to 5,6MHz (USB)

Output stage (each channel)

1 x 6922/ECC88

Headphone impedance

> 16ohm, high fidelity driver

Headphone power out

> 90mW (600ohm)
> 300mW (32ohm)

Output Level

1,5V RMS

Frequency Response

from 20Hz to 20KHz 0dB

S/N Ratio

> 95dB, A weighted

Dimensions (w,d,h)

260x380x95mm

Weight

5Kg

Line power

117 / 230 / 245 Vac, 50/60 Hz (see rear label)

Fuse

See rear label

Power consumption

40W max

PC requirements

1GHz processor, 512MB RAM, USB 2.0 port
